3003 2RS Double Row Angular Contact Ball Bearing Radial Well Sealed Auti Dust

Double row Angular Contact Ball Bearing Radial well sealed auti dust Ball Bearings 3003 2RS for farm machine tractor

Product Description

Desription:

Double row angular contact ball bearings can withstand larger radial load and axial joint load and torque load, limit the axial displacement of the two aspects. Mainly used for limiting the axial displacement of the shaft and the shell.
Double row angular contact ball bearing inner and outer ring of the tilt between the limited, allowing the tilt angle depends on the internal clearance of the bearing, bearing size, internal design and role in bearing the force and torque, and the maximum allowable inclination angle should ensure that the bearing will not produce high additional stress.

Data:

size			Model	Basis Load ratings		Limited Speed
				Dynamic	Static	Grease	Oil
10	26	12	3000	5.5	3.2	18000	23000
	26	12	3000-2RS	5.5	3.2	18000
	26	12	3000-2Z	5.5	3.2	18000
12	28	12	3001	6.1	3.7	17000	22000
	28	12	3001-2RS	6.1	3.7	17000
	28	12	3001-2Z	6.1	3.7	17000
15	32	13	3002	8.5	5.4	14500	18000
	32	13	3002-2RS	8.5	5.4	14500
	32	13	3002-2RS	8.5	5.4	14500
17	35	14	3003	9	6	12500	16000
	35	14	3003-2RS	9	6	12500
	35	14	3003-2Z	9	6	12500
20	32	10	3804	4.9	3.9	13000	14300
	32	10	3804-2RS	4.9	3.9	13000
	32	10	3804-2Z	4.9	3.9	13000
	37	13	3904	9.3	6.6	12000	13200
	37	13	3904-2RS	9.3	6.6	12000
	37	13	3904-2Z	9.3	6.6	12000

Application:Electricity, cranes, oil, natural gas, mining, agriculture, papermaking machinery, reduction gears, railway vehicle axles, rolling mill gearbox seats, rolling mills, roller tables, crushers, vibrating screens, printing machinery, woodworking machinery, and various industrial applications Reducer, vertical self-aligning bearing with seat,etc.

Angular contact ball bearing include:
1) Single row angular contact ball bearing
2) Matched angular contact ball bearing
3) Double row angular contact ball bearing
4) Four-point contact ball bearing

Angular contact ball bearings features :
1) Load capacities are higher than deep groove ball bearings of same dimensions;
2) Used for bearing radial-axial combined loads or pure thrust loads;
3) Low operating friction and high limiting speed.
